- Casing parameters compliant with EN1886 standard: T2, TB2, L1, D1, F9
Quality
Compact Casing
- Casing material – Magnelis® (magnesium-zinc coating)
- Mineral wool insulation – panel thickness: 50 mm
- Mechanically poured gasket
High Efficiency
- Rotary heat exchanger: condensing or sorption
- HEX counterflow heat exchanger: aluminium
- Highly efficient fan sets with electronically commutated (EC) motors
Compact Size
- Ability to move the unit through a 900 mm door
- Air handling unit base configuration: heat recovery, fan sets, filters, heater (optional)
Easy to Maintain and Clean
- Access to the unit from both sides
- Easy access for cleaning fan sets and heat exchangers
Controls
- Multifunctional controls integrated with the unit – configured and ready to operate (Plug&Play)
- mHMI application available as standard on the unit
- Possibility of remote management when connected to the VTS cloud
